Laboratories

Facilities

The Automobile Engineering Department has the following Laboratory facilities.

o

Laboratory Name

Equipment Name

Automotive Engine Testing Lab



svce-ae

  • Automotive multi-cylinder SI engines with eddy current dynamometer
  • Automotive multi-cylinder CI engines with eddy current dynamometer with piezoelectric pick up & angle encoder
  • Two wheeler engine test rig
  • Single cylinder CI and SI engines
  • Four stroke and two stroke cut section engine models
  • Eddy current, hydraulic and electrical dynamometer ECB -120, ECB200,ECB -450
  • AVL Indimodule System
  • Tata Dicor CRDI Engine
  • AVL Smoke Meter & AVL Five Gas Analyzer

Engine Components Lab



svce-ae

  • Hyundai Santro 4-cylinder petrol engine
  • Endura 4-cylinder diesel engine
  • Ashok Leyland 6-cylinder diesel engine
  • Tata 6-cylinder diesel engine
  • Ambassador 4-cylinder petrol engine
  • Maruti 3-cylinder petrol engine
  • Maruti 4-cylinder petrol engine
  • Nissan 4-cylinder petrol engine
  • Cut section model of 4-cylinder petrol engine
  • Cut section model of two stroke TVS 50 engine

Two And Three Wheelers Lab



svce-ae

  • Computerized chain test rig
  • Computerized shock absorber test rig
  • Two wheeler engines with transmission system
  • Three wheeler engines with transmission system
  • Three wheeler chassis
  • Royal Enfield single cylinder four stroke petrol engine
  • Shock Absorber Test Rig

Chassis Components Lab



svce-ae

  • Ashok Leyland Chassis
  • Ambassador Car
  • Maruti Omni car
  • Maruti Omni Car -Full demo model
  • Premier padmini car
  • Hyundai Santro car- Left hand drive
  • Maruti 800 -Car body
  • Willys Jeep
  • Hybrid electric vehicle
  • Ashok Leyland -Air brake system
  • Hydraulic Brake system
  • Transfer case
  • Synchromesh & Constant mesh gearbox
  • Fluid Coupling

Vehicle Maintenance Lab



svce-ae

  • Fuel Injection Pump calibration test bench
  • Cylinder reboring and Valve refacing machine
  • Head light beam adjuster
  • Semi automatic tire changer
  • Wheel alignment Apparatus
  • Engine Analyzer

Auto Electrical Lab





  • Test bench to calibrate and benchmark the automotive accessories
  • Equipments to check all automotive electrical appliances
  • Battery Tester
  • Ignition Coil Tester
  • Spark Plug Tester

Fuels And Lubricants Lab



svce-ae

  • Ramsbottom Carbon Residue Apparatus
  • Ash Content Apparatus
  • Weighing Machine for .1 mg
  • Bomb Calorimeter Apparatus
  • Junkers Calorimeter
  • Saybolt Viscometer
  • Redwood Viscometer
  • Cloud and Pour Point Apparatus
  • Ables flash point (manual)
  • Ables flash point (Refrigerated)
  • Copper Strip Corrosion Test
  • Flash and fire point open cup
    ASTM Distillation test
  • Drop Point Test
  • RVP test
  • Aniline Point Apparatus
  • Mechanical Penetration test
  • Kinematic Viscosity Bath Apparatus
  • Refrigeration (as cold Storage device)

Cad Lab



svce-ae





Hardware Details:

Sl.No

Hardware Details

  1. SERVER Intel xenon processor 3 GHz = 1 no
    4 GB RAM, 160 GB HDD, 17inch TFT monitor
  2. Intel core2 quad processor 2.83 GHz = 1no
    4 GB RAM, 160 GB HDD, 19inch LCD monitor
  3. Intel Pentium dual core processor 2.8 GHz = 5nos
    4 GB RAM, 160 GB HDD, 17inch TFT monitor
  4. Intel Pentium dual core processor 2.8 GHz = 10nos
    2 GB RAM, 160 GB HDD, 17inch TFT monitor
  5. Intel core i3 processor 2.93 GHz = 23nos
    8 GB DDR3 RAM, 320 GB SATA HDD, 18.5inch TFT monitor
  6. Intel Pentium core 2 duo processor 2.93 GHz = 1nos                                         2 GB RAM, 160 GB SATA HDD, 18.5inch TFT Monitor


CAD Software:
Software available (Required as per Curriculum):
AutoCAD 2008
Pro E wildfire 5.0

Additional software available :
Star CD
Ansys 12.0
Adams R3
CADEM
Operating Systems Available :
1. Windows 2003 server
2.windows XP Professional
3. windows 7
