Department of Civil Engineering

CADD LABORATORY

• Computer system (33 Numbers)
• Drafting and Analysis software
  • AutoCAD,
  • STAAD Pro,
  • E-TABS,
  • MATLAB
• Open-Source Software
  • Primavera

CONCRETE AND HIGHWAY ENGINEERING LABORATORY

• Universal Testing Machine (1000 kN)
• Compression Testing Machine (2000 kN) with Flexural Test set up (100 kN)
• California Bearing Ratio Test Apparatus
• Aggregate Impact Testing Machine
• Los-Angeles Abrasion Testing Machine
• Ductility Testing Machine
• Universal Penetrometer with automatic time controller and bitumen penetration kit
• Compaction Factor Apparatus, Slump Cone, Flow Table, Vee Bee Consistometer for Workability Tests
• Concrete Mixer (1 cft)
• Benkelman Beam
• L Box & V Funnel apparatus
• Radar Speed Gun
• Digital Rebound hammer

ENVIRONMENTAL ENGINEERING LABORATORY

• Water Analyzer
• Spectrophotometer
• Ion Selective Electrode Meter
• Flame Photometer
• DO/BOD Analyzer
• pH Meter
• Turbidity Meter
• Conductivity Meter
• COD Apparatus
• Jar Test Apparatus
• Hot Air Oven
• BOD Incubator
• Water Bath
• Muffle Furnace
• Magnetic Stirrer with hot plate
• Weighing Balance – 220 g capacity and readability with 0.001 g

FLUID MECHANICS AND MACHINERY LABORATORY

• Centrifugal pump (Single and Multi-Stage)
• Reciprocating Pump
• Submersible Pump
• Gear Pump
• Pelton Wheel Turbine
• Francis Turbine
• Kaplan Turbine
• Venturimeter
• Orificemeter
• Pipe Friction Apparatus (Major and Minor Losses)
• Rotameter
• Bernoulli’s Apparatus
• Metacentric Height Apparatus
• Hydraulic Flume

SOIL MECHANICS LABORATORY

• Direct Shear Test Setup
• Permeability Test Apparatus
• Vane Shear Test Apparatus
• Triaxial Compression Test Setup
• Three Gang Consolidation Test Setup
• Unconfined Compression Test Setup
• Hydrometer
• Proctor Compaction Test Apparatus
• Liquid Limit, Plastic Limit and Shrinkage Limit Test Apparatus
• Sieve Shaker with set of Sieves

STRENGTH OF MATERIALS LABORATORY

• Computerized Hydraulic 200 kN Universal Testing Machine
• Universal Testing Machine (100 kN)
• Compression Testing Machine (2000 kN)
• Rockwell and Brinell Hardness Testing Machine
• Izod and Charpy Impact Testing Machine
• Torsion Testing Machine
• Spring testing Machine
• Vicat Apparatus
• Rosette strain gauges setup with five channel indicators to test cantilever beam and shaft setup for bending and torque measurement
• Brinell Hardness testing machine

SURVEY LABORATORY

• Total Station
• Theodolite
• Auto Level
• Dumpy level
• Prismatic and Surveyor Compass
• Chains and Accessories
• Hand Held GPS
• Laser Distance Meter

ADDITIONAL FACILITIES

STRUCTURAL AND APPLIED MECHANICS LABORATORY

• Clarke’s Maxwell Reciprocal Theorem Apparatus
• Behaviour of Column & Struts Apparatus
• Portal Frame Apparatus
• Suspension Bridge Apparatus
• Redundant Joint Apparatus
• Three Hinged Arch Apparatus
• Two Hinged Arch Apparatus
• Bending Moment & Shear Force Apparatus
• Pin Jointed Truss Apparatus

MODEL LABORATORY

• Slab Reinforcement with T Beam
• Dog Legged Staircase
• Plate Girder Bridge
• RCC Column Footing
• Combined Footing (Trapezoidal)
• Cantilever Retaining Wall
• Counter Fort Retaining Wall
• Coffer Dam
• Arch Dam
• Earthen Dam
• Gravity Dam
• River Head Work
• Canal Regulator
• Sluice Gate
• Spill Way Gate
• Canal Drop
• Syphon Aqueduct
• Aqueduct
• Cross Section National Highway
• Clover Leaf Junction
• Diamond Pattern
• Point Crossing
• Inter Locking
• Level Crossing

RESEARCH FACILITIES

ANRF SPONSORED RESEARCH LABORATORY

• Laboratory Concrete Mixer Pan type (40 Liter Capacity)
• Concrete Impact Testing machine
• Flexural Jig Assembly
• Cube moulds for concrete and mortar
• Cylindrical moulds (150 x 300 mm)
• Prism moulds (100 x100 x 500 mm)

CENTRE FOR ADVANCED STRUCTURAL TESTING (CAST)

• 50 T Loading frame with following accessories
  • Hydraulic Jack
  • Hydraulic Pump Assembly
  • High Pressure Hydraulic Jack Hose
• Concrete Impermeability Apparatus with Compressor
• Rapid Chloride Penetration for Concrete
• Beam Mould Made of 5mm MS Plate
• Facilities for testing Self Compacting Concrete
  • U-Box Test Apparatus
  • V-Funnel Apparatus
  • J-Ring Apparatus
  • L-Box Apparatus
• Electronic Weighing Balance
• Digital length comparator
